MPR-4 Series
The Next Generation of Network Analyzers

MPR-4 Series panel type network analyzers are a compact solution with a size of 96 x 96 x 45 mm for detailed measurement and analysis of electrical parameters. It has a wide operating voltage december of 50-270 VAC/DC.
Devices with up to 16 MB of internal memory provide a wide range of 1/0 solutions with a modular structure that can be changed according to needs and areas of use, allowing you to detect and control the status of devices in the field.
Instant monitoring via the device with a large LCD display is supported. Thanks to the communication feature of the MPR-4 series, energy measurements can be easily monitored from a single monitoring center.

* Digital input/output, analog output and relay measurement options with modular 1/0 structure
• 96 x 96 x 45 mm thin design
• 3.5" segment LCD display
• 16 MB of memory
* Current & voltage imbalance measurement
•    51. detailed measurement up to the harmonic
• 256 event records
•    ?compatible with lug meter current transformers
* Sag/Swell measurement
* Active energy class 0.5 (optional)
* IP54 protection class •optional)
