EMK-01 Class A Quality Analyzer

EMK-01 quality analyzer for AG and MV systems
It provides measurement of electrical parameters according to EN 61000-4-30 Class A standard.
The Class A quality analyzer monitors and analyzes the quality of the energies on the distribution and consumption side of the networks according to the EN 50160 standard in order to detect problems in the system.

• Short-time and long-time fliker measurement according to EN 61000-4-15 standard
* Transient detection and recording (>25 µs)
* Detect outages and Sag & Swell events
and save (>1 O µs)
•    65. measuring up to the harmonic
* Harmonic and dechormonic measurement in accordance with EN 61000-4-7 standard (VLN, VLL, 1)
* Active energy class 0.2
* Sampling frequency of 40 kHz
• 1 GB of internal memory
• 1/0, which can be set to 2 digital inputs/outputs
* Temperature sensor
